APC SMTL750RM2UC uninterruptible power supply (UPS) Line-Interactive 0.75 kVA
APC

SMTL750RM2UC uninterruptible power supply (UPS) Line-Interactive 0.75 kVA

600 W 6 AC outlet(s)

Model SMTL750RM2UCEAN 731304341994

52 specifications
  • Battery150 Ah
  • TypeRackmount
  • Weight15.4 kg
  • ColourBlack, Silver
  • UPS topologyLine-Interactive
  • AC outlet typesNEMA 5-15R
See all specifications

Overview

Battery
150 Ah
Type
Rackmount
Weight
15.4 kg
Colour
Black, Silver
UPS topology
Line-Interactive
AC outlet types
NEMA 5-15R
Brand
APC
Model
SMTL750RM2UC
Part number
SMTL750RM2UC
EAN / UPC
731304341994
Also known as
APC SMTL750RM2UC uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 600 W 6 AC outlet(s)

Specifications

52 specifications in 9 groups

Features

UPS topologyLine-Interactive
Output power capacity0.75 kVA
Output power600 W
WaveformPure sine
Input operation voltage (min)82 V
Input operation voltage (max)144 V
Input frequency50/60 Hz
Surge energy rating680 J
Response time6 ms
Efficiency96%
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)5%
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet typesNEMA 5-15R
Power plugNEMA 5-15P
AC outlets quantity6 AC outlet(s)
USB portYes
Serial interfaceYes
Serial interface typeRJ-45
SmartSlotYes

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery capacity150 Ah
Battery life (max)10 year(s)
Battery recharge time3 h
Hot-swap batteryYes
Cold startYes

Design

Form factorRackmount
Product colourBlack, Silver
Rack capacity2U
Cable length2.44 m
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Rack mount kitYes
Cables includedRS-232, USB cable
ManualYes
Quick installation guideYes

Certificates

Compliance certificatesRoHS

Weight & dimensions

Width438 mm
Depth318 mm
Height86 mm
Weight15.4 kg

Packaging data

Package width584 mm
Package depth472 mm
Package height229 mm
Package weight17.7 kg
