APC Smart-UPS X 2200VA

APC Smart-UPS X 2200VA

Model Smart-UPS X 2200VAPart no. SMX2200R2HVNCEAN 731304327738

64 specifications
  • Battery702 Ah
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight37.4 kg
  • ColourBlack
  • UPS topologyLine-Interactive
See all specifications

Overview

Battery
702 Ah
Noise
55 dB
Type
Rackmount/Tower
Weight
37.4 kg
Colour
Black
UPS topology
Line-Interactive
Brand
APC
Model
Smart-UPS X 2200VA
Part numbers
SMX2200R2HVNC, SMX2200HVNC
EAN / UPC
731304327738, 731304327158, 7313043271584
Also known as
APC Smart-UPS X SMX2200R2HVNC - 2200VA, 8x C13, 1x C19 outlet, USB, expandable runtime, NMC

Specifications

64 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)208 V
Input operation voltage (max)230 V
Input frequency50/60 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output frequency regulation+/- 3 Hz
Output voltage regulation5%
Surge energy rating645 J
Response time10 ms
Emergency Power Off (EPO)Yes
Noise level55 dB
Surge protectionYes
Audible alarm(s)Yes
Web-based managementYes
Audible alarm modesBattery replacement
Auto-restartYes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
AC outlets quantity9 AC outlet(s)
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports1
SmartSlotYes
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity702 Ah
Battery recharge time3 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity2U
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Rack mount kitYes
Cables includedInput power cable, USB cable
Management card includedYes
Quick installation guideYes

Certificates

Compliance certificatesRoHS
CertificationCE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE

Weight & dimensions

Width432 mm
Depth667 mm
Height85 mm
Weight37.4 kg

Packaging data

Resource CDYes
Package width596 mm
Package depth869 mm
Package height243 mm
Package weight45.3 kg

Logistics data

Products per pallet8 pc(s)
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)3167.15

Other features

Output voltage230 V
