APC Galaxy VS UPS 40kW
APC

Galaxy VS UPS 40kW

400V for External Batteries, Start-up 5x8

Model GVSUPS40KHSEAN 731304342748

52 specifications
  • Noise65 dB
  • TypeTower
  • Weight210 kg
  • ColourWhite
  • UPS topologyDouble-conversion (Online)
  • SmartSlotYes
See all specifications

Overview

Noise
65 dB
Type
Tower
Weight
210 kg
Colour
White
UPS topology
Double-conversion (Online)
SmartSlot
Yes
Brand
APC
Model
GVSUPS40KHS
Part number
GVSUPS40KHS
EAN / UPC
731304342748, 5705154118865
Also known as
APC Galaxy VS UPS 40kW 400V for External Batteries, Start-up 5x8

Specifications

52 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity40 kVA
Output power40000 W
WaveformSine
Input operation voltage (min)340 V
Input operation voltage (max)460 V
Input frequency40/70 Hz
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Output frequency50/60 Hz
Output voltage regulation3%
Maximum current74 A
Heat dissipation3845.4 BTU/h
Number of input phases3
Number of output phases3
Efficiency96.5%
Input power factor0.99
Crest factor2.5:1
ECO modeYes
Output voltage Total Harmonic Distortion (THD)3%
Noise level65 dB
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm

Ports & interfaces

SmartSlotYes
SmartConnect portNo

Battery

Battery technologyLithium-Ion (Li-Ion)

Design

Form factorTower
Product colourWhite
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP21

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 55 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)10 - 80%
Operating altitude0 - 984.3 m
Non-operating altitude0 - 15000 m

Packaging content

Management card includedYes

Certificates

CertificationCSA C22.2 NO. 107.3, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, FCC Part 15 Class A, IEC 60721-4-2 Level 2M2, UL 1778 5th edition

Weight & dimensions

Width521 mm
Depth847 mm
Height1485 mm
Weight210 kg

Packaging data

Package width640 mm
Package depth990 mm
Package height1680 mm
Package weight235 kg

Logistics data

Harmonized System (HS) code85078000
Warranty period1 year(s)

Other features

Input connection type4-wire (3PH + G), 5-wire (3PH + N + G)
Nominal input voltage400 V
Nominal output voltage400 V
