G3HT30KHB1S uninterruptible power supply (UPS) Double-conversion (Online) 30 kVA
24000 W
Model G3HT30KHB1SEAN 731304285823
46 specifications
- Noise54.5 dB
- TypeTower
- Weight446 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
- AC outlet typesHard Wire 5-wire (3PH + N + G)
Overview
- Noise
- 54.5 dB
- Type
- Tower
- Weight
- 446 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- AC outlet types
- Hard Wire 5-wire (3PH + N + G)
- Brand
- APC
- Model
- G3HT30KHB1S
- Part number
- G3HT30KHB1S
- EAN / UPC
- 731304285823
- Also known as
- APC G3HT30KHB1S uninterruptible power supply (UPS) Double-conversion (Online) 30 kVA 24000 W
Specifications
46 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 30 kVA |
| Output power | 24000 W |
| Waveform | Sine |
| Input operation voltage (min) | 323 V |
| Input operation voltage (max) | 477 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Maximum current | 65 A |
| Input power factor | 0.99 |
| Crest factor | 2.5:1 |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Input current Total Harmonic Distortion (THD) | 5% |
| Noise level | 54.5 dB |
| Power protection features | Overload |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | Hard Wire 5-wire (3PH + N + G) |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 192 V |
| Battery life (max) | 5 year(s) |
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Product colour | Black |
| Display type | LCD |
| International Protection (IP) code | IP20 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 9000 m |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Quick installation guide | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, IEC 61000-4-5, IEC 62040-2, TUV, VFI-SS-111 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 500 mm |
| Depth | 950 mm |
| Height | 1300 mm |
| Weight | 446 kg |
Packaging data
| Specification | Value |
|---|---|
| Software CD | Yes |
| Package width | 800 mm |
| Package depth | 965 mm |
| Package height | 1440 mm |
| Package weight | 472 kg |
