APC Easy UPS SMV
APC

Easy UPS SMV

Model Easy UPS SMVPart no. SMV750CAIEAN 7313043465624

53 specifications
  • Battery9 Ah
  • Noise45 dB
  • TypeTower
  • Weight25.2 kg
  • ColourBlack
  • UPS topologyLine-Interactive
See all specifications

Overview

Battery
9 Ah
Noise
45 dB
Type
Tower
Weight
25.2 kg
Colour
Black
UPS topology
Line-Interactive
Brand
APC
Model
Easy UPS SMV
Part numbers
SMV750CAI, SMV3000CAI, SMV2000CAI, SMV1500CAI, SMV1000CAI
EAN / UPC
7313043465624, 731304346555, 7313043465556, 731304346548 +3 more
Also known as
APC Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support

Specifications

53 specifications in 9 groups

Features

UPS topologyLine-Interactive
Output power capacity3 kVA
Output power2100 W
WaveformSine
Input operation voltage (min)157 V
Input operation voltage (max)303 V
Input frequency45/65 Hz
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Output frequency50/60 Hz
Output voltage regulation-1 - 1%
Automatic Voltage Regulation (AVR)Yes
Maximum current25 A
Crest factor3:1
Noise level45 dB
Power protection featuresOverload, Short circuit
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet typesIEC 320
AC outlets quantity6 AC outlet(s)
USB portYes
SmartSlotNo
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity9 Ah
Battery voltage12 V
Number of batteries supported4
Battery life (max)5 year(s)
Battery recharge time4 h
Cold startYes
Battery weight28.9 kg

Design

Form factorTower
Product colourBlack
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m

Packaging content

Cables includedUSB cable
Management card includedNo
ManualYes

Certificates

CertificationCE

Weight & dimensions

Width180 mm
Depth455 mm
Height240 mm
Weight25.2 kg
Battery width32.6 cm
Battery depth60.1 cm
Battery height41 cm

Logistics data

Harmonized System (HS) code85078000
