APC Easy UPS ONLINE SRV RM Ext. 3000VA230V

APC Easy UPS ONLINE SRV RM Ext. 3000VA230V

Model Easy UPS ONLINE SRV RM Ext. 3000VA230VPart no. SRV3KRILRKEAN 731304405221

53 specifications
  • Noise50 dB
  • TypeRackmount
  • Weight9.5 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesC13 coupler, C19 coupler
See all specifications

Overview

Noise
50 dB
Type
Rackmount
Weight
9.5 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
C13 coupler, C19 coupler
Brand
APC
Model
Easy UPS ONLINE SRV RM Ext. 3000VA230V
Part number
SRV3KRILRK
EAN / UPC
731304405221, 3540260184272, 8592978285210
Also known as
APC Easy UPS ONLINE SRV RM Ext. 3000VA230V uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2400 W 7 AC outlet(s)

Specifications

53 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity3 kVA
Output power2400 W
WaveformPure sine
Input operation voltage (min)110 V
Input operation voltage (max)285 V
Input frequency40/70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation3%
Surge energy rating600 J
Efficiency88%
Crest factor3:1
Noise level50 dB
Surge protectionYes
Detachable power cordYes
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
AC outlets quantity7 AC outlet(s)
USB portYes
USB port typeUSB Type-B
Serial interfaceYes
RS-232 ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage72 V
Battery life (max)5 year(s)
Battery recharge time5.5 h
Charging current4 A

Design

Form factorRackmount
Product colourBlack
Rack capacity4U
Cable length1.5 m
Display typeLCD
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Rack mount kitYes
Cables includedInput power cable, Output power cable, RS-232, USB cable
ManualYes

Weight & dimensions

Width86 mm
Depth438 mm
Height432 mm
Weight9.5 kg

Packaging data

Package width554 mm
Package depth240 mm
Package height700 mm
Package weight1.8 kg

Logistics data

Harmonized System (HS) code85078000
