APC Easy UPS On-Line SRV
APC

Easy UPS On-Line SRV

Model Easy UPS On-Line SRVPart no. SRV1KRI-EEAN 731304436881

74 specifications
  • Noise50 dB
  • TypeRackmount
  • Weight11.5 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesC13 coupler
See all specifications

Overview

Noise
50 dB
Type
Rackmount
Weight
11.5 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
C13 coupler
Brand
APC
Model
Easy UPS On-Line SRV
Part number
SRV1KRI-E
EAN / UPC
731304436881
Also known as
APC Easy UPS On-Line, 1000VA/900W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit

Specifications

74 specifications in 12 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power900 W
WaveformSine
Input operation voltage (min)110 V
Input operation voltage (max)285 V
Input frequency40 - 70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation3%
Surge energy rating945 J
Number of input phases1
Number of output phases1
Single-phase input voltage supported230 V
Efficiency88%
Crest factor3:1
Output voltage Total Harmonic Distortion (THD)3%
Noise level50 dB
Surge protectionYes
Audible alarm(s)Yes
Audible alarm modesOverload alarm, Low battery alarm
Detachable power cordYes
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler
Power plugC15 coupler
AC outlets quantity3 AC outlet(s)
USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-B
Serial interfaceYes
RS-232 ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage24 V
Battery life (max)3 year(s)
Battery recharge time4 h
Replacement battery cartridgeAPCRBCV200

Design

Form factorRackmount
Product colourBlack
Rack capacity2U
Cable length1.5 m
Display typeLCD
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Rack mount kitYes
Cables includedOutput power cable, RS-232, USB cable, Input power cable
ManualYes

Certificates

Compliance certificatesRoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) complianceYes
CertificationCE; UKCA; TISI

Technical details

Packaging recycled materialsRecycled cardboard
Preferred mounting positionlower
Packaging without single use plasticNo
Sustainable packagingNo
Take-back systemNo

Weight & dimensions

Width438 mm
Depth312 mm
Height86 mm
Weight11.5 kg

Packaging data

Package width551 mm
Package depth455 mm
Package height218 mm
Package weight14 kg

Logistics data

Customs product code (TARIC)8504409590
Country of originChina

Other features

Input connection typeIEC 60320 C14
Mountingfront; horizontal
Output connection type3 IEC 60320C13
Output voltage230 V
