APC E3SUPS10KHB uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA
APC

E3SUPS10KHB uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA

10000 W

Model E3SUPS10KHBEAN 731304340737

47 specifications
  • Noise60 dB
  • TypeTower
  • Weight112 kg
  • ColourWhite
  • UPS topologyDouble-conversion (Online)
  • Parallel ports quantity1
See all specifications

Overview

Noise
60 dB
Type
Tower
Weight
112 kg
Colour
White
UPS topology
Double-conversion (Online)
Parallel ports quantity
1
Brand
APC
Model
E3SUPS10KHB
Part number
E3SUPS10KHB
EAN / UPC
731304340737, 5054444765297
Also known as
APC E3SUPS10KHB uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W

Specifications

47 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity10 kVA
Output power10000 W
WaveformPure sine
Input operation voltage (min)304 V
Input operation voltage (max)415 V
Input frequency45/65 Hz
Output operation voltage (min)380 V
Output operation voltage (max)477 V
Output frequency50/60 Hz
Maximum current18 A
Number of input phases3
Number of output phases3
Efficiency94.8%
Input power factor0.99
ECO modeYes
Output voltage Total Harmonic Distortion (THD)3%
Noise level60 dB

Ports & interfaces

Parallel ports quantity1
SmartSlotYes
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage240 V

Design

Form factorTower
Product colourWhite
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 999.9 m
Non-operating altitude0 - 15000 m

Packaging content

Management card includedNo
Quick installation guideYes

Certificates

CertificationCE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE REACH

Weight & dimensions

Width380 mm
Depth928 mm
Height1400 mm
Weight112 kg

Packaging data

Package width563 mm
Package depth1014 mm
Package height1640 mm
Package weight145 kg

Logistics data

Harmonized System (HS) code85078000

Other features

Nominal input voltage400 V
Nominal output voltage400 V
