APC Back-UPS, 1200VA, Tower
APC

Back-UPS, 1200VA, Tower

230V, 4x CEE 7/7 Schuko outlets, AVR

Model BX1200MI-GREAN 731304410867

57 specifications
  • Noise40 dB
  • TypeCompact
  • Weight7.6 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesType F
See all specifications

Overview

Noise
40 dB
Type
Compact
Weight
7.6 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
Type F
Brand
APC
Model
BX1200MI-GR
Part number
BX1200MI-GR
EAN / UPC
731304410867
Also known as
APC Back-UPS, 1200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR

Specifications

57 specifications in 10 groups

Features

UPS topologyLine-Interactive
Output power capacity1.2 kVA
Output power650 W
WaveformSine
Input operation voltage (min)140 V
Input operation voltage (max)300 V
Input frequency50/60 Hz
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Output frequency50/60 Hz
Output frequency regulation0.5 Hz
Output voltage regulation10%
Automatic Voltage Regulation (AVR)Yes
Surge energy rating273 J
Response time6 ms
Input power factor0.54
Noise level40 dB
Surge protectionYes
Audible alarm(s)Yes
Audible alarm modesLow battery alarm

Ports & interfaces

AC outlet typesType F
Power plugType F
AC outlets quantity4 AC outlet(s)
USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-B
Ethernet LAN (RJ-45) ports2
SmartSlotNo
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Typical backup time at full load1 min
Typical backup time at half load5 min
Battery life (max)2 year(s)
Battery recharge time8 h

Design

Form factorCompact
Product colourBlack
Cable length1.2 m
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m

Packaging content

Cables includedInput power cable
Management card includedNo
ManualYes

Certificates

Compliance certificatesRoHS
CertificationCB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2

Weight & dimensions

Width140 mm
Depth390 mm
Height190 mm
Weight7.6 kg

Packaging data

Package width235 mm
Package depth495 mm
Package height297 mm
Package weight8.6 kg

Logistics data

Harmonized System (HS) code85078000
