E Line Curved LCD monitor with Ultra Wide-Color 328E9FJAB/00

Model 328E9FJAB/00EAN 8712581750039

128 specifications Checked today

Display80 cm (31.5")
Resolution2560 x 1440 pixels
Energy classC
ColourBlack, Silver
AMD FreeSyncYes
Market positioningHome

See all specifications

Overview

Display: 80 cm (31.5")
Resolution: 2560 x 1440 pixels
Energy class: C
Colour: Black, Silver
AMD FreeSync: Yes
Market positioning: Home

Brand: Philips
Category: Monitor
Model: 328E9FJAB/00
Part number: 328E9FJAB/00
EAN / UPC: 8712581750039
Also known as: Philips E Line Curved LCD monitor with Ultra Wide-Color 328E9FJAB/00

Specifications

128 specifications in 15 groups

Display

Specification	Value
Display diagonal	80 cm (31.5")
Display resolution	2560 x 1440 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Quad HD
Panel type	VA
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	4 ms
Display surface	Gloss
Anti-glare screen	Yes
Screen shape	Curved
Supported graphics resolutions	2560 x 1440
Aspect ratio	16:9
Contrast ratio (typical)	3000:1
Contrast ratio (dynamic)	20000000:1
Dynamic contrast ratio marketing name	SmartContrast
Maximum refresh rate	75 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.272 x 0.272 mm
Pixel density	93 ppi
Horizontal scan range	70 - 115 kHz
Vertical scan range	48 - 75 Hz
Viewable size, horizontal	69.7 cm
Viewable size, vertical	39.2 cm
Digital horizontal frequency	70 - 115 kHz
Digital vertical frequency	48 - 75 Hz
Sync-on-green (SOG)	Yes
Display diagonal (metric)	80 cm
DDC/CI	Yes
Haze rate	25%
Colour gamut standard	sRGB, NTSC
Colour gamut	102%
sRGB coverage (typical)	122.6%
NTSC coverage (typical)	102%
3D	No
Separate H/V sync	Yes
Display sRGB	Yes
Display panel size	31.5 inch / 80 cm

Performance

Specification	Value
AMD FreeSync	Yes
Component video sync	Separate Sync, Sync-on-green (SOG)
Flicker-free technology	Yes
Low Blue Light technology	Yes
Windows operating systems supported	Yes
Mac operating systems supported	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	6 W
Built-in camera	No

Design

Specification	Value
Market positioning	Home
Product colour	Black, Silver
Feet colour	Silver

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
DVI port	No
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Yes
Headphone outputs	1
PC Audio in	Yes
HDCP	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	No
Tilt adjustment	Yes
Tilt angle range	-5 - 20°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian
Number of OSD languages	21
Plug and Play	Yes
LED indicators	Operation, Stand-by

Power

Specification	Value
Energy efficiency class (SDR)	C
Power consumption (typical)	60.35 W
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Relative humidity	20 - 80%

Weight & dimensions

Specification	Value
Dimensions (W x D x H) with stand	713 x 525 x 236 mm
Width (with stand)	713 mm
Depth (with stand)	236 mm
Height (with stand)	525 mm
Weight (with stand)	6.78 kg
Width (without stand)	713 mm
Depth (without stand)	52 mm
Height (without stand)	425 mm
Weight (without stand)	6.4 kg

Packaging data

Specification	Value
Package dimensions (WxDxH)	827 x 626 x 233 mm
Package width	827 mm
Package depth	233 mm
Package height	626 mm
Package weight	10.4 kg

Packaging content

Specification	Value
Stand included	Yes
Manual	Yes

Other features

Specification	Value
Compatible operating systems	Mac OS X; Windows 10 / 8.1 / 8 / 7
On/off switch	Yes
TV tuner integrated	No
Exterior finish type	Gloss
Colour	No
Compliance certificates	RoHS
Effective viewing area	697.3 x 392.3 mm
Energy efficiency class (legacy scale)	C
Heavy metals free	Hg (mercury), Pb (lead)
LowBlue mode	Yes
Monitor sync input signal	Separate Sync; Sync on Green
No flickering	Yes
Signal input	VGA (Analog ); DisplayPort x 1; HDMI (digital, HDCP)
Mean time between failures (MTBF)	50000 h
Certification	CE Mark, FCC Class B, CU-EAC, TUV/ISO9241-307, RCM, BSMI, PSB, MEPS, CB, cETLus
Picture enhancement	SmartImage game
Regulatory Approvals	CE Mark; FCC Class B; CU-EAC; TUV/ISO9241-307; RCM; BSMI; PSB; MEPS; CB; cETLus
User controls	Power On/Off; Menu; Brightness; Input; SmartImage Game
Supplied AC adapter type	AC

Recycling data

Specification	Value
Packaging recyclability rate	100%

Thin Client

Specification	Value
Thin client installed	No

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
