E24u G4 FHD USB-C Monitor

Model E24u G4 FHD USB-C MonitorPart no. 189T0AAEAN 195122124205

113 specifications Checked today

Overview

113 specifications in 15 groups

Specification	Value
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Full HD
Panel type	IPS
Backlight type	Edge LED
Display brightness (typical)	250 cd/m²
Response time	5 ms
Display surface	Matt
Anti-glare screen	Yes
Screen shape	Flat
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA)
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	5000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.274 x 0.274 mm
Pixel density	93 ppi
Horizontal scan range	30 - 80 kHz
Vertical scan range	50 - 60 Hz
Display diagonal (metric)	60.5 cm
Surface hardness	3H
Colour depth	8 bit
Colour gamut standard	NTSC
Colour gamut	72%
NTSC coverage (typical)	72%
Display bezel technology	Micro-Edge

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	65 W
DVI port	No
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DisplayPort version	1.2
Audio input	No
Headphone out	No
HDCP	Yes

Specification	Value
Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	14 kWh
Power consumption (typical)	22 W
Power consumption (standby)	0.5 W
Power consumption (max)	131 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	20 - 80%

Specification	Value
Stand included	Yes
Cables included	AC

Specification	Value
Sustainability certificates	ENERGY STAR
Sustainable technologies and materials	Arsenic-free display glass; Low halogen; Mercury-free display backlights; TCO Certified; TCO Certified Edge
Sustainability compliance	Yes

Specification	Value
Carbon emissions, end-of-life (kg of CO2e)	2
Carbon emissions, logistics (kg of CO2e)	3
Carbon emissions, manufacturing (kg of CO2e)	136
Total carbon emissions, w/o use phase (kg of CO2e)	80
Total carbon footprint (kg of CO2e)	220

Specification	Value
Compliance certificates	BIS, BSMI, CB, CCC, CE, CECP, CEL, EAC, Federal Communications Commission (FCC), GS mark, KCC, Norma Oficial Mexicana (NOM), VCCI, WEEE, cTUVus
Depth	47 mm
Height	323.3 mm
Weight	6.3 kg
Width	539.4 mm
UNSPSC-code	43211902
Supplied AC adapter type	195122124021
