EIZO 17" Class Color LCD Monitor

EIZO 17" Class Color LCD Monitor

Model 17" Class Color LCD MonitorPart no. L560T-C-BKEAN 690592006650

37 specifications Checked yesterday

Display43.2 cm (17")
Resolution1280 x 1024 pixels
ColourBlack
NVIDIA G-SYNCNo
Number of upstream ports1
Panel mounting interface100 x 100 mm

See all specifications

Overview

Display: 43.2 cm (17")
Resolution: 1280 x 1024 pixels
Colour: Black
NVIDIA G-SYNC: No
Number of upstream ports: 1
Panel mounting interface: 100 x 100 mm

Brand: EIZO
Category: Monitor
Model: 17" Class Color LCD Monitor
Part number: L560T-C-BK
EAN / UPC: 690592006650, 690592024999, 4995047013624, 4995047031963
Also known as: EIZO 17" Class Color LCD Monitor computer monitor 43.2 cm (17") 1280 x 1024 pixels Touchscreen Black

Specifications

37 specifications in 8 groups

Display

Specification	Value
Display diagonal	43.2 cm (17")
Display resolution	1280 x 1024 pixels
Touchscreen	Yes
Display brightness	180 cd/m²
Response time	25 ms
Screen shape	Flat
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.78 million colours
Pixel pitch	0.264 x 0.264 mm
Horizontal scan range	30 - 81 kHz
Vertical scan range	49.5 - 75.5 Hz
Viewable size diagonal	43.2 cm
Digital horizontal frequency	30 - 65 kHz
Digital vertical frequency	59 - 61 Hz

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Design

Specification	Value
Product colour	Black

Ports & interfaces

Specification	Value
Number of upstream ports	1
DVI port	Yes
DVI-D ports quantity	1
DVI-I ports quantity	1

Ergonomics

Specification	Value
Panel mounting interface	100 x 100 mm
Height adjustment	82

Power

Specification	Value
Power consumption (typical)	35 W
Power consumption (PowerSave)	1 W

Weight & dimensions

Specification	Value
Dimensions (W x D x H) with stand	380 x 209 x 443 mm
Width (with stand)	380 mm
Depth (with stand)	209 mm
Height (with stand)	443 mm
Weight (with stand)	8.2 kg
Weight (without stand)	5.2 kg

Other features

Specification	Value
Dimensions (WxDxH)	380 x 58 x 353 mm
Display viewable area (HxV)	338 x 270 mm
Power management	VESA DPMS, DVI-DMPM
Certification	CE, TÜV GM (IEC 60601)
