MSI WT73VR 7RM-687US
MSI

WT73VR 7RM-687US

Model WT73VR 7RM-687USPart no. WT73VR687EAN 824142146446

146 specifications Checked today
  • Display43.9 cm (17.3")
  • Resolution3840 x 2160 pixels
  • ProcessorIntel® Xeon® E3 v6
  • Memory64 GB
  • Storage1.51 TB
  • GraphicsNVIDIA® Quadro® P5000
See all specifications

Overview

Display
43.9 cm (17.3")
Resolution
3840 x 2160 pixels
Processor
Intel® Xeon® E3 v6
Memory
64 GB
Storage
1.51 TB
Graphics
NVIDIA® Quadro® P5000
Brand
MSI
Category
Laptop
Model
WT73VR 7RM-687US
Part numbers
WT73VR687, WT73VR 7RM-687US
EAN / UPC
824142146446
Also known as
MSI Workstation WT73VR 7RM-687US Intel® Xeon® E3 v6 E3-1505MV6 Mobile workstation 43.9 cm (17.3") 4K Ultra HD 64 GB DDR4-SDRAM 1.51 TB HDD+SSD NVIDIA® Quadro® P

Specifications

146 specifications in 19 groups

Design

Product typeMobile workstation
Product colourBlack
Form factorClamshell

Display

Display diagonal43.9 cm (17.3")
Display resolution3840 x 2160 pixels
TouchscreenNo
HD type4K Ultra HD
LED backlightYes
Native aspect ratio16:9

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon® E3 v6
Processor modelE3-1505MV6
Processor cores4
Processor threads8
Processor boost frequency4 GHz
Processor frequency3 GHz
System bus rate8 GT/s
Processor cache8 MB
Processor cache typeSmart Cache
Processor socketBGA 1440
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameKaby Lake
Bus typeDMI3
SteppingB0
Thermal Design Power (TDP)45 W
Configurable TDP-down35 W
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 1x8+2x4, 2x8
PCI Express slots version3.0
ECC supported by processorYes

Memory

Internal memory64 GB
Internal memory typeDDR4-SDRAM
Memory clock speed2133 MHz
Memory slots4x SO-DIMM
Maximum internal memory64 GB

Storage

Total storage capacity1.51 TB
Storage mediaHDD+SSD
Number of HDDs installed1
HDD capacity1 TB
HDD speed7200 RPM
SSD capacity512 GB
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

On-board graphics cardYes
Discrete graphics cardYes
Discrete graphics card modelNVIDIA® Quadro® P5000
Discrete graphics card memory16 GB
Discrete graphics memory typeGDDR5
On-board graphics card modelIntel® HD Graphics P630
Maximum on-board graphics card memory1.7 GB
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.4
On-board graphics card ID0x591D

Audio

Number of built-in speakers2
Speaker power6 W
Built-in subwooferYes
Built-in microphoneYes

Camera

Front cameraYes
Front camera resolution1920 x 1080 pixels
Video capturing speed30 fps

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version4.2

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity0
Mini DisplayPorts quantity1
DVI portNo
VGA (D-Sub) ports quantity0
Thunderbolt ports quantity0
Headphone outputs1
Microphone inYes
Docking connectorNo

Performance

Motherboard chipsetIntel® CM238

Keyboard

Pointing deviceTouchpad
Keyboard backlitYes
Numeric keypadYes
Windows keysYes

Software

Operating system installedWindows 10 Pro
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Flex Memory AccessYes
Intel HD GraphicsYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Smart Response Technology version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel Stable Image Platform Program (SIPP) version1.00
Intel TSX-NIYes
Intel TSX-NI version1.00
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID97463
Processor codeSR32K
Processor package size42 x 28 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes
Conflict-Free processorYes

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery capacity75 Wh

Power

AC adapter power230 W
AC adapter frequency50 - 60 Hz
DC-in jackYes

Weight & dimensions

Weight4.14 kg
Width428 mm
Depth287 mm
Height (front)2.4 cm
Height (rear)4.9 cm

Packaging content

AC adapter includedYes
ManualYes

Other features

3DNo
