MSI Creator M16 HX C14VFG-073XES

Creator M16 HX C14VFG-073XES

Model Creator M16 HX C14VFG-073XESPart no. CREATOR M16 HX C14VFG-073XESEAN 4711377197779

100 specifications Checked today

Display40.6 cm (16")
Resolution2560 x 1600 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 4060

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 2560 x 1600 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 4060

Brand: MSI
Category: Laptop
Model: Creator M16 HX C14VFG-073XES
Part number: CREATOR M16 HX C14VFG-073XES
EAN / UPC: 4711377197779
Also known as: MSI Creator M16 HX C14VFG-073XES Intel® Core™ i7 i7-14700HX Laptop 40.6 cm (16") Touchscreen Quad HD+ 16 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 4060 Wi-Fi 6E

Specifications

100 specifications in 19 groups

Design

Specification	Value
Product type	Laptop
Product colour	Grey
Colour name	Lunar Gray
Form factor	Clamshell
Market positioning	Gaming

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	2560 x 1600 pixels
Touchscreen	Yes
HD type	Quad HD+
Panel type	IPS
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	240 Hz

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	Intel® Core™ i7 (14th gen)
Processor model	i7-14700HX
Processor cores	20
Processor threads	28
Processor boost frequency	5.5 GHz
Processor frequency	5.5 GHz
Performance cores	8
Efficient cores	12
Performance-core Max Turbo Frequency	5.5 GHz
Efficient-core Max Turbo Frequency	3.9 GHz
Performance-core base frequency	2.1 GHz
Efficient-core base frequency	1.5 GHz
Processor cache	33 MB
Processor cache type	Smart Cache
Maximum turbo power	157 W
Processor base power	55 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	2 x 8 GB
Memory slots	2x SO-DIMM
Maximum internal memory	96 GB
Memory data transfer rate	5600 MT/s

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0, PCI Express 5.0
SSD form factor	M.2

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4060
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics

Audio

Specification	Value
Audio system	Hi-Res Audio
Number of built-in speakers	4
Speaker power	2 W

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Video capturing speed	30 fps
Infrared (IR) camera	Yes

Network

Specification	Value
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
Headphone outputs	1
Combo headphone/mic port	Yes
Microphone in	Yes

Performance

Specification	Value
Motherboard chipset	Intel HM770
Ambient light sensor	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard backlit colour	White
Copilot key	Yes

Software

Specification	Value
Operating system installed	No

Battery

Specification	Value
Number of battery cells	4
Battery capacity	65 Wh

Power

Specification	Value
AC adapter power	180 W
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Face recognition	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Certificates

Specification	Value
Certification	Meta Ready

Weight & dimensions

Specification	Value
Weight	2.38 kg
Width	359 mm
Depth	266.4 mm
Height (front)	2.18 cm
Height (rear)	2.77 cm

Other features

Specification	Value
Warranty period	3 year(s)
