ThinkPad W700 + ThinkVision L197

Model ThinkPad W700 + ThinkVision L197Part no. 27585GM + 4434HE1

107 specifications Checked today

Overview

Brand: Lenovo
Category: Laptop
Model: ThinkPad W700 + ThinkVision L197
Part numbers: 27585GM + 4434HE1, 2758A18 + 4434HE1
Also known as: Lenovo ThinkPad W700 + ThinkVision L197 Intel® Core™ 2 Extreme X9100 43.2 cm (17") 4 GB DDR3-SDRAM 320 GB NVIDIA® Quadro® FX 3700M Windows Vista Business

107 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ 2 Extreme
Processor model	X9100
Processor cores	2
Processor threads	2
Processor frequency	3.06 GHz
Processor cache	6 MB
Processor cache type	L2
Processor front side bus	1066 MHz
Processor socket	Socket 478
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Extreme X9000 Series
Processor codename	Penryn
Bus type	FSB
FSB Parity	No
Stepping	C0
Thermal Design Power (TDP)	44 W
Tjunction	105 °C
Number of Processing Die Transistors	410 M
Processing Die size	107 mm²
CPU multiplier (bus/core ratio)	12
ECC supported by processor	No

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	NVIDIA® Quadro® FX 3700M
Maximum graphics card memory	1.024 GB

Specification	Value
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	0
HDMI ports quantity	0
DVI port	Yes
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	No
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	0
CardBus PCMCIA slot type	No
SmartCard slot	No
Modem (RJ-11) ports	0
TV-in port	No
TV-out	No
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	0

Specification	Value
Operating system installed	Windows Vista Business

Specification	Value
Intel® Wireless Display (Intel® WiDi)	No
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Processor ARK ID	35431
Processor code	SLB48
Processor package size	35 x 35 mm
Thermal Monitoring Technologies	No
Conflict-Free processor	No
