ThinkPad W500 + ThinkVision L2240p
Model ThinkPad W500 + ThinkVision L2240pPart no. 40623NM + 4422HB6
106 specifications Checked today
- Display39.1 cm (15.4")
- Resolution1920 x 1200 pixels
- ProcessorIntel® Core™2 Duo
- Memory4 GB
- Storage320 GB
- GraphicsAMD Mobility FireGL V5700
Overview
- Display
- 39.1 cm (15.4")
- Resolution
- 1920 x 1200 pixels
- Processor
- Intel® Core™2 Duo
- Memory
- 4 GB
- Storage
- 320 GB
- Graphics
- AMD Mobility FireGL V5700
- Brand
- Lenovo
- Category
- Laptop
- Model
- ThinkPad W500 + ThinkVision L2240p
- Part numbers
- 40623NM + 4422HB6, 4062A27 + 4422HB6
- Also known as
- Lenovo ThinkPad W500 + ThinkVision L2240p Intel® Core™2 Duo T9800 39.1 cm (15.4") 4 GB 320 GB AMD Mobility FireGL V5700 Windows Vista Business
Specifications
106 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.1 cm (15.4") |
| Display resolution | 1920 x 1200 pixels |
| Native aspect ratio | 16:10 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™2 Duo |
| Processor model | T9800 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 2.93 GHz |
| Processor cache | 6 MB |
| Processor cache type | L2 |
| Processor front side bus | 1066 MHz |
| Processor socket | Socket 479 |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Core 2 Duo T9000 Series |
| Processor codename | Penryn |
| Bus type | FSB |
| FSB Parity | No |
| Stepping | E0 |
| Thermal Design Power (TDP) | 35 W |
| Tjunction | 105 °C |
| Number of Processing Die Transistors | 410 M |
| Processing Die size | 107 mm² |
| CPU multiplier (bus/core ratio) | 11 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Memory clock speed | 1066 MHz |
| Memory layout (slots x size) | 2 x 2 GB |
| Maximum internal memory | 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 320 GB |
| HDD speed | 7200 RPM |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Mobility FireGL V5700 |
| Maximum graphics card memory | 0.5 GB |
Network
| Specification | Value |
|---|---|
| Networking type | Vodafone WWAN |
| Wireless technology | Intel Wireless WiFi Link 5300 3x3 AGN |
| Bluetooth | Yes |
| Bluetooth version | 2.0+EDR |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 0 |
| HDMI ports quantity | 0 |
| DVI port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Firewire (IEEE 1394) ports | 1 |
| Headphone outputs | 1 |
| S/PDIF out port | No |
| Microphone in | Yes |
| Docking connector | Yes |
| ExpressCard slot | Yes |
| CardBus PCMCIA slots quantity | 1 |
| CardBus PCMCIA slot type | No |
| SmartCard slot | No |
| Modem (RJ-11) ports | 0 |
| TV-in port | No |
| TV-out | No |
| PS/2 ports quantity | 0 |
| Parallel ports quantity | 0 |
| Serial ports quantity | 0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Vista Business |
Processor special features
| Specification | Value |
|---|---|
| Intel® Wireless Display (Intel® WiDi) | No |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | No |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Turbo Boost Technology | No |
| Processor ARK ID | 37005 |
| Processor code | SLGES |
| Processor package size | 35 x 35 mm |
| Thermal Monitoring Technologies | No |
| Conflict-Free processor | No |
Battery
| Specification | Value |
|---|---|
| Number of battery cells | 9 |
| Battery life (max) | 8.3 h |
Security
| Specification | Value |
|---|---|
| Fingerprint reader | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.63 kg |
| Width | 357.5 mm |
| Depth | 255 mm |
| Height | 29.5 mm |
| Dimensions (WxDxH) | 357.5 x 255 x 29.5 mm |
Other features
| Specification | Value |
|---|---|
| Infrared data port | No |
| Internal modem | Yes |
| Intel segment tagging | Professional |
| Supplied AC adapter type | AC |
