Legion5 Pro i7 32GB 1TB W11H
Model Legion5 Pro i7 32GB 1TB W11HPart no. 82RF00SVTXEAN 196803497779
126 specifications Checked today
- Display40.6 cm (16")
- Resolution2560 x 1600 pixels
- ProcessorIntel® Core™ i7
- Memory32 GB
- Storage1 TB
- GraphicsNVIDIA GeForce RTX 3060
Overview
- Display
- 40.6 cm (16")
- Resolution
- 2560 x 1600 pixels
- Processor
- Intel® Core™ i7
- Memory
- 32 GB
- Storage
- 1 TB
- Graphics
- NVIDIA GeForce RTX 3060
- Brand
- Lenovo
- Category
- Laptop
- Model
- Legion5 Pro i7 32GB 1TB W11H
- Part number
- 82RF00SVTX
- EAN / UPC
- 196803497779
- Also known as
- Lenovo Legion5 Pro i7 32GB 1TB W11H Intel® Core™ i7 i7-12700H Laptop 40.6 cm (16") WQXGA DDR5-SDRAM SSD NVIDIA GeForce RTX 3060 Wi-Fi 6E (802.11ax) Windows 11 H
Specifications
126 specifications in 20 groups
Design
| Specification | Value |
|---|---|
| Product type | Laptop |
| Product colour | Grey |
| Colour name | Storm Grey |
| Form factor | Clamshell |
| Housing material | Aluminium |
| Market positioning | Gaming |
| Introduction year | 2022 |
| Refurbished | No |
| Country of origin | China |
| Original brand name | Lenovo |
Display
| Specification | Value |
|---|---|
| Display diagonal | 40.6 cm (16") |
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| Foldable display | No |
| HD type | WQXGA |
| Panel type | IPS |
| Native aspect ratio | 16:10 |
| Display surface | Matt |
| Anti-glare screen | Yes |
| Display brightness | 500 cd/m² |
| Colour gamut | 100% |
| RGB colour space | sRGB |
| Maximum refresh rate | 240 Hz |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor model | i7-12700H |
| Processor cores | 14 |
| Processor boost frequency | 4.7 GHz |
| Processor frequency | 2.3 GHz |
| Performance-core Max Turbo Frequency | 4.7 GHz |
| Efficient-core Max Turbo Frequency | 3.5 GHz |
| Performance-core base frequency | 2.3 GHz |
| Efficient-core base frequency | 1.7 GHz |
| Performance-core boost frequency | 4.7 GHz |
| Efficient-core boost frequency | 3.5 GHz |
| Processor cache | 24 MB |
| Processor cache type | L3 |
| Configurable TDP-down | 35 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory channels | Dual-channel |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| NVMe | Yes |
| SSD interface | M.2 |
| SSD form factor | M.2 |
| Optical drive type | No |
| Card reader integrated | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Discrete graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce RTX 3060 |
| Discrete graphics card memory | 6 GB |
| Discrete graphics memory type | GDDR6 |
| NVIDIA G-SYNC | Yes |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3287 |
| Audio system | Nahimic Audio |
| Number of built-in speakers | 2 |
| Speakers manufacturer | Nahimic |
| Speaker power | 2 W |
| Built-in subwoofer | No |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera HD type | HD |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Specification | Value |
|---|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel SoC |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Numeric keypad | Yes |
| Keyboard backlit colour | RGB |
| Keyboard backlit zone | 4-zone RGB |
| Keyboard layout | QWERTY |
| Keyboard language | Turkish |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Home |
| Operating system architecture | 64-bit |
| Operating system language | English, Turkish |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity | 80 Wh |
| Battery life (max) | 6.5 h |
Power
| Specification | Value |
|---|---|
| AC adapter power | 300 W |
Security
| Specification | Value |
|---|---|
| Fingerprint reader | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.49 kg |
| Width | 359.9 mm |
| Depth | 264.4 mm |
| Height | 19.9 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 569 mm |
| Package depth | 85 mm |
| Package height | 346 mm |
| Package weight | 3.44 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | No |
