HP EliteBook 745 G6 Notebook PC 8RF96UP

EliteBook 745 G6 Notebook PC 8RF96UP

Model EliteBook 745 G6 Notebook PC 8RF96UPPart no. 8RF96UPEAN 194441712155

89 specifications Checked today

Display35.6 cm (14")
Resolution1920 x 1080 pixels
ProcessorAMD Ryzen™ 7 PRO
Memory16 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 1920 x 1080 pixels
Processor: AMD Ryzen™ 7 PRO
Memory: 16 GB
Storage: 512 GB
Graphics: Not available

Brand: HP
Category: Laptop
Model: EliteBook 745 G6 Notebook PC 8RF96UP
Part number: 8RF96UP
EAN / UPC: 194441712155
Also known as: HP EliteBook 745 G6 Notebook PC 8RF96UP AMD Ryzen™ 7 PRO 3700U Laptop 35.6 cm (14") Full HD 16 GB DDR4-SDRAM 512 GB SSD Wi-Fi 5 (802.11ac) Windows 10 Pro Silver

Specifications

89 specifications in 17 groups

Design

Specification	Value
Product type	Laptop
Product colour	Silver
Form factor	Clamshell
Market positioning	Premium
Country of origin	China

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1080 pixels
Touchscreen	No
HD type	Full HD
Panel type	IPS
Native aspect ratio	16:9
Display brightness	250 cd/m²
Colour gamut	45%
Display diagonal (metric)	35.56 cm
RGB colour space	NTSC

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 7 PRO
Processor generation	AMD Ryzen PRO 3000 Series
Processor model	3700U
Processor cores	4
Processor boost frequency	4 GHz
Processor frequency	2.3 GHz
Processor cache	4 MB
Processor cache type	L3

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Memory clock speed	2666 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x SO-DIMM

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	NVMe, PCI Express
Optical drive type	No
Card reader integrated	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board GPU manufacturer	AMD
On-board graphics card model	AMD Radeon Vega

Audio

Specification	Value
Audio system	Bang & Olufsen
Number of built-in speakers	2
Built-in microphone	Yes
Number of microphones	3

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Infrared (IR) camera	Yes

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Dual Band Wireless-AC 9260
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.0
Miracast	Yes

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.0
Combo headphone/mic port	Yes

Keyboard

Specification	Value
Pointing device	Clickpad
Keyboard backlit	Yes
Numeric keypad	No
Spill-resistant keyboard	Yes

Software

Specification	Value
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit

Brand-specific features

Specification	Value
HP speaker type	HP Dual Speakers
HP front camera	HP Webcam HD IR
HP Security tools	Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; Power-on authentication; Preboot authentication; TPM 2.0 embedded security chip shipped with Windows 10 (Common Criteria EAL4+ Certied); HP Sure Click; Windows Defender; HP Sure Run Gen2; HP Sure Recover Gen2; HP BI
HP Management tools	HP Driver Packs; HP System Software Manager (SSM); HP BIOS Cong Utility (BCU); HP Client Catalog; Ivanti Management Suite; HP Manageability Integration Kit Gen3
HP segment	Business

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	50 Wh

Power

Specification	Value
AC adapter power	65 W
DC-in jack	Yes

Certificates

Specification	Value
Low halogen	Yes
Certification	ENERGY STAR

Weight & dimensions

Specification	Value
Weight	1.48 kg
Width	326 mm
Depth	234.3 mm
Height	17.9 mm
