ASUS Zenbook 17 Fold OLED UX9702AA-FOLED-MD731X Intel® Core™ i7 i7-1250U Hybrid (2-in-1)

Zenbook 17 Fold OLED UX9702AA-FOLED-MD731X Intel® Core™ i7 i7-1250U Hybrid (2-in-1)

43.9 cm (17.3") Touchscreen 16 GB LPDDR5-SDRAM 1 TB SSD Wi-Fi 6E (802.1

Model UX9702AA-FOLED-MD731XPart no. 90NB0WX1-M003F0EAN 4711081858461

106 specifications Checked today

Display43.9 cm (17.3")
Resolution2560 x 1920 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage1 TB
GraphicsNot available

See all specifications

Overview

Display: 43.9 cm (17.3")
Resolution: 2560 x 1920 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 1 TB
Graphics: Not available

Brand: ASUS
Category: Laptop
Model: UX9702AA-FOLED-MD731X
Part number: 90NB0WX1-M003F0
EAN / UPC: 4711081858461
Also known as: ASUS Zenbook 17 Fold OLED UX9702AA-FOLED-MD731X Intel® Core™ i7 i7-1250U Hybrid (2-in-1) 43.9 cm (17.3") Touchscreen 16 GB LPDDR5-SDRAM 1 TB SSD Wi-Fi 6E (802.1

Specifications

106 specifications in 19 groups

Design

Specification	Value
Product type	Hybrid (2-in-1)
Product colour	Black
Colour name	Tech Black
Form factor	Clamshell
Housing material	Aluminium, Magnesium
Market positioning	Home

Display

Specification	Value
Display diagonal	43.9 cm (17.3")
Display resolution	2560 x 1920 pixels
Touchscreen	Yes
Touchscreen type	Resistive
Foldable display	Yes
Display diagonal (unfolded)	31.8 cm (12.5")
Display resolution (unfolded)	1920 x 1280 pixels
Panel type	OLED
LED backlight	Yes
Native aspect ratio	4:3
Display brightness	500 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1000000:1
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	HDR True Black 500

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	12th gen Intel® Core™ i7
Processor model	i7-1250U
Processor cores	10
Processor boost frequency	4.7 GHz
Processor frequency	1.1 GHz
Processor cache	12 MB
Processor cache type	Smart Cache

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR5-SDRAM
Memory form factor	On-board
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics

Audio

Specification	Value
Audio system	Smart Amp
Number of built-in speakers	4
Speakers manufacturer	Harman Kardon
Built-in microphone	Yes
Number of microphones	4

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.0

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
HDMI ports quantity	0
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes

Performance

Specification	Value
Orientation sensor	Yes
Voice control	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No

Software

Specification	Value
Operating system installed	Windows 11 Pro
Trial software	Microsoft 365
Bundled software	MyASUS

Processor special features

Specification	Value
Intel® Evo™ Platform Verified	Yes
CPU configuration (max)	1
Embedded options available	No
Execute Disable Bit	Yes
Intel Flex Memory Access	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	75 Wh

Power

Specification	Value
AC adapter power	65 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.25 A
AC adapter output voltage	20 V

Security

Specification	Value
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Weight & dimensions

Specification	Value
Weight	1.5 kg
Width	378.5 mm
Depth	287.6 mm
Height (front)	8.7 mm
Height (rear)	1.29 cm

Packaging content

Specification	Value
Cables included	USB Type-C to USB Type-A
