ASUS K72F-TY233V Intel® Pentium® P6200
ASUS

K72F-TY233V Intel® Pentium® P6200

43.9 cm (17.3") HD+ 3 GB DDR3-SDRAM 320 GB Windows 7 Home Premium Brown

Model K72F-TY233VPart no. 90NY7A214S3D32VL225EAN 884840766223

145 specifications Checked today
  • Display43.9 cm (17.3")
  • Resolution1600 x 900 pixels
  • ProcessorIntel® Pentium®
  • Memory3 GB
  • Storage320 GB
  • Battery2200 mAh
See all specifications

Overview

Display
43.9 cm (17.3")
Resolution
1600 x 900 pixels
Processor
Intel® Pentium®
Memory
3 GB
Storage
320 GB
Battery
2200 mAh
Brand
ASUS
Category
Laptop
Model
K72F-TY233V
Part number
90NY7A214S3D32VL225
EAN / UPC
884840766223, 884840778981
Also known as
ASUS K72F-TY233V Intel® Pentium® P6200 43.9 cm (17.3") HD+ 3 GB DDR3-SDRAM 320 GB Windows 7 Home Premium Brown

Specifications

145 specifications in 20 groups

Design

Product colourBrown

Display

Display diagonal43.9 cm (17.3")
Display resolution1600 x 900 pixels
HD typeHD+
LED backlightYes
Native aspect ratio16:9

Processor

Processor manufacturerIntel
Processor familyIntel® Pentium®
Processor modelP6200
Processor cores2
Processor threads2
Processor frequency2.13 GHz
System bus rate2.5 GT/s
Processor cache3 MB
Processor cache typeSmart Cache
Processor socketPGA988
Processor lithography32 nm
Processor operating modes64-bit
Processor seriesIntel Pentium P6000 Series for Mobile
Processor codenameArrandale
Bus typeDMI
FSB ParityNo
Thermal Design Power (TDP)35 W
Tjunction90 °C
Maximum number of PCI Express lanes1
PCI Express configurations1x16
PCI Express slots version2.0
Number of Processing Die Transistors382 M
Processing Die size81 mm²
CPU multiplier (bus/core ratio)16
ECC supported by processorNo

Memory

Internal memory3 GB
Internal memory typeDDR3-SDRAM
Memory clock speed1066 MHz
Memory layout (slots x size)1 x 1 + 1 x 2 GB
Memory slots2x SO-DIMM
Maximum internal memory8 GB

Storage

Total storage capacity320 GB
Number of HDDs installed1
HDD interfaceSATA
HDD speed5400 RPM
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Compatible memory cardsMemory Stick (MS), MMC, MS PRO, SD

Graphics

On-board graphics cardYes
Graphics card familyIntel
On-board graphics card familyIntel® HD Graphics
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)667 MHz

Audio

Audio systemSRS PS
Number of built-in speakers2
Speakers manufacturerAltec Lansing
Speaker power2 W
Audio system full duplexYes
Audio system direct 3D soundYes

Camera

Front camera resolution (numeric)0.3 MP

Network

Wi-FiYes
Networking featuresGigabit Ethernet
Wireless technologyWi-Fi
Ethernet LANYes
BluetoothNo
Cabling technology10/100/1000Base-T(X)

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
eSATA/USB 2.0 ports quantity0
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
eSATA ports quantity0
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity0
DVI portNo
VGA (D-Sub) ports quantity1
Firewire (IEEE 1394) ports0
Thunderbolt ports quantity0
Headphone outputs1
S/PDIF out portNo
Microphone inYes
Docking connectorNo
ExpressCard slotNo
CardBus PCMCIA slots quantity0
CardBus PCMCIA slot typeNo
SmartCard slotNo
Modem (RJ-11) ports0
TV-outNo

Performance

Motherboard chipsetIntel® HM55 Express

Keyboard

Pointing deviceTouchpad
Full-size keyboardYes
Keyboard key pitch1.9 cm

Software

Operating system installedWindows 7 Home Premium
Operating system architecture64-bit

Processor special features

Intel® Wireless Display (Intel® WiDi)No
CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Graphics & IMC lithography45 nm
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Demand Based SwitchingNo
Intel Dual Display Capable TechnologyYes
Intel Enhanced Halt StateYes
Intel FDI TechnologyYes
Intel Fast Memory AccessYes
Intel Flex Memory AccessYes
Intel Rapid Storage TechnologyNo
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)No
Intel Virtualization Technology (VT-x)No
Intel Virtualization Technology for Directed I/O (VT-d)No
Intel® AES New Instructions (Intel® AES-NI)No
Intel® Anti-Theft Technology (Intel® AT)No
Intel® Clear Video HD Technology (Intel® CVT HD)No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® InTru™ 3D TechnologyNo
Intel® Insider™No
Intel® My WiFi Technology (Intel® MWT)No
Intel® Quick Sync Video TechnologyNo
Intel® Smart CacheYes
Intel® Turbo Boost TechnologyNo
Physical Address Extension (PAE)36 bit
Physical Address Extension (PAE)Yes
Processor ARK ID50176
Processor package size37.5x37.5 mm
Thermal Monitoring TechnologiesYes
Conflict-Free processorNo

Battery

Battery capacity2200 mAh

Power

AC adapter power90 W
AC adapter input voltage100 - 240 V
AC adapter output current4.74 A
AC adapter output voltage19 V
DC-in jackYes

Security

Cable lock slotNo

Weight & dimensions

Weight3.11 kg
Width420 mm
Depth281 mm
Height (front)3.5 cm
Height (rear)3.74 cm

Packaging content

AC adapter includedYes

Other features

Infrared data portNo
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Power supply typeAC/DC
Supplied AC adapter typeAC
