TravelMate 6592G-5B2G12Mn + Ez Dock II

Model TravelMate 6592G-5B2G12Mn + Ez Dock IIPart no. LX.TNW06.005-B

97 specifications Checked today

Overview

Brand: Acer
Category: Laptop
Model: TravelMate 6592G-5B2G12Mn + Ez Dock II
Part numbers: LX.TNW06.005-B, LX.TNW06.005-BUN
Also known as: Acer TravelMate 6592G-5B2G12Mn + Ez Dock II Intel® Core™2 Duo T5670 39.1 cm (15.4") 2 GB DDR2-SDRAM 120 GB AMD Mobility Radeon HD 2400 XT Windows XP Professiona

97 specifications in 17 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Duo
Processor model	T5670
Processor cores	2
Processor threads	2
Processor frequency	1.8 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Processor socket	LGA 3647 (Socket P)
Processor lithography	65 nm
Processor operating modes	64-bit
Processor codename	Merom
Bus type	FSB
Stepping	M0
Thermal Design Power (TDP)	35 W
Tjunction	100 °C
Number of Processing Die Transistors	291 M
Processing Die size	143 mm²
CPU multiplier (bus/core ratio)	9

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	AMD Mobility Radeon HD 2400 XT
Maximum graphics card memory	0.5 GB

Specification	Value
Audio system	High Definition Audio
Number of built-in speakers	2

Specification	Value
Front camera resolution (numeric)	0.3 MP

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	0
DVI port	Yes
VGA (D-Sub) ports quantity	1
Firewire (IEEE 1394) ports	1
Headphone outputs	1
S/PDIF out port	No
Microphone in	Yes
Docking connector	Yes
ExpressCard slot	Yes
CardBus PCMCIA slots quantity	1
CardBus PCMCIA slot type	Type II
SmartCard slot	Yes
Modem (RJ-11) ports	1
TV-in port	No
TV-out	Yes
TV-out type	S-Video
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	1
USB 1.1 ports quantity	0

Specification	Value
Pointing device	Touchpad
Keyboard function keys	12

Specification	Value
Operating system installed	Windows XP Professional
Bundled software	Acer Empowering Technology (eDataSecurity Management / eLock Management / ePerformance Management / eRecovery Management / eSettings Management / eNet Management / ePower Management / ePresentation Management), Acer Bio-Protection, Acer Video Conference Manager, Acer Crystal Eye, Acer GridVista, Ace

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	No
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	No
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	No
Processor ARK ID	35163
Processor code	SLAJ5
Processor package size	35 x 35 mm
