Acer HELIOS NEO 16 I7 16GB 512GB 5060

HELIOS NEO 16 I7 16GB 512GB 5060

Model HELIOS NEO 16 I7 16GB 512GB 5060Part no. NH.U4REK.00AEAN 4711721146422

133 specifications Checked yesterday

Display40.6 cm (16")
Resolution1920 x 1200 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage512 GB
Battery92 Wh

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 1920 x 1200 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 512 GB
Battery: 92 Wh

Brand: Acer
Category: Laptop
Model: HELIOS NEO 16 I7 16GB 512GB 5060
Part number: NH.U4REK.00A
EAN / UPC: 4711721146422
Also known as: Acer Predator Helios Neo 16 PHN16-I31-70B2 Gaming Notebook

Specifications

133 specifications in 20 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Colour name	Black
Form factor	Clamshell
Market positioning	Gaming
Country of origin	China
AI-powered	Yes

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	WUXGA
Display technology marketing name	ComfyView
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:10
Display surface	Matt
Anti-glare screen	Yes
Display brightness	400 cd/m²
Colour gamut	100%
Display diagonal (metric)	40.6 cm
RGB colour space	sRGB
Maximum refresh rate	180 Hz
sRGB coverage (typical)	100%
Contrast ratio (typical)	1000:1
Anti-microbial screen	No

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor model	i7-14650HX
Processor cores	16
Processor threads	24
Processor boost frequency	5.2 GHz
Processor frequency	2.2 GHz
Processor cache	30 MB
Processor operating modes	64-bit

Neural processor unit (NPU)

Specification	Value
Copilot+ PC	No

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory form factor	SO-DIMM
Memory slots	2x SO-DIMM
Maximum internal memory	32 GB

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA® GeForce RTX™ 5060 Laptop GPU
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR7

Audio

Specification	Value
Audio system	DTS:X Ultra
Built-in speaker(s)	Yes
Number of built-in speakers	2
Built-in microphone	Yes
Number of microphones	3

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels

Network

Specification	Value
Mobile network connection	No
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	802.11a, 802.11ad, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
WLAN controller model	Killer Wi-Fi 6E 1675i
Ethernet LAN	Yes
Ethernet LAN data rates	5000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.4

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	2
Combo headphone/mic port	Yes
Line-in	Yes
HDCP	Yes
HDMI	Yes
Line-out	Yes
USB ports quantity	5
USB Type-C DisplayPort Alternate Mode	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	4-zone RGB
Keyboard layout	QWERTY
Keyboard language	UK English
Copilot key	Yes
Keyboard special features	Predator Sense Key

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Microsoft Copilot	Yes
Bundled software	Windows Desktop Apps In-House: Acer QuickPanel PredatorSense V5 (NB) Tools: Acer My Key Application

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	92 Wh
Battery life (max)	10 h
Fast charging	Yes

Power

Specification	Value
AC adapter power	330 W
USB Type-C charging port	Yes
USB Type-C required charging power (max)	100 W
USB Type-C required charging power (min)	90 W
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	No
Trusted Platform Module (TPM)	Yes
HDD recovery	Yes

Weight & dimensions

Specification	Value
Weight	2.5 kg
Width	356.8 mm
Depth	275.5 mm
Height	26.8 mm
Height (front)	2.23 cm
Height (rear)	2.67 cm

Packaging data

Specification	Value
Package width	80 mm
Package depth	548 mm
Package height	346 mm
Package weight	4.85 kg

Packaging content

Specification	Value
AC adapter included	Yes
Keyboard included	Yes
Power cord included	Yes
Packaging content	Helios Neo 16 PHN16-I31-70B2 Gaming Notebook Lithium Ion (Li-Ion) Battery Power Adapter Power Cord Warranty Card

Other features

Specification	Value
Security features	Firmware Trusted Platform Module (TPM) solution Kensington lock
Chipset	Intel®
Manufacturer	Acer, Inc
