Product comparison · 2 network transceiver modules

ATGBICS 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM) vs ATGBICS SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM)

29specifications compared
7differ
22identical
0known for one product only

Key differences

Maximum data transfer rate
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):2500 Mbit/s
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):100 Mbit/s
SFP transceiver standard
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):ZX
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):LX
Maximum transfer distance
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):80000 m
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):20000 m
Wavelength
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):1550 nm
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):1310 nm
Ethernet interface type
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):2.5 Gigabit Ethernet
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):Fast Ethernet
Fiber ethernet cabling technology
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):2GBASE
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):100BASE
Brand compatibility
- 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM):Actelis
- SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM):FiberPlex

Side by side

Differences highlightedShow differences only

Comparison of 506R51714-C, SFP-SC03XC-3131-B-C
29 specifications	A ATGBICS 506R51714 Actelis compatible Transceiver SFP 2.5GBase-ZX (1550nm SMF 80km LC DOM) Model 506R51714-C View product	B ATGBICS SFP-SC03XC-3131-B FiberPlex compatible Transceiver SFP 100Base-LX (1310nm SMF 20km LC DOM) Model SFP-SC03XC-3131-B-C View product
Performance6 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rateDiffers	2500 Mbit/s	100 Mbit/s
Interface type	SFP	SFP
Single-mode fiber (SMF) supported	Yes	Yes
Multi-mode fiber (MMF) supported	No	No
Fiber optic connector	LC	LC
SFP transceiver standardDiffers	ZX	LX
Maximum transfer distanceDiffers	80000 m	20000 m
WavelengthDiffers	1550 nm	1310 nm
Ethernet LAN	Yes	Yes
Ethernet interface typeDiffers	2.5 Gigabit Ethernet	Fast Ethernet
Fiber ethernet cabling technologyDiffers	2GBASE	100BASE
Digital Diagnostics Monitoring (DDM)	Yes	Yes
Export Control Classification Number (ECCN)	5A991	5A991
Features1 differ
Product colour	Silver	Silver
Housing material	Metal	Metal
Plug and Play	Yes	Yes
Hot-Plug support	Yes	Yes
Hot-swap	Yes	Yes
Easy to install	Yes	Yes
Brand compatibilityDiffers	Actelis	FiberPlex
Certificatesidentical
Compliance certificates	TÜV mark, UKCA, UL, US FDA, REACH, Federal Communications Commission (FCC), RoHS, CE	TÜV mark, UKCA, UL, US FDA, REACH, Federal Communications Commission (FCC), RoHS, CE
Certification	CE, UKCA, EMC, FCC, REACH, RoHS, TÜV, FDA	CE, UKCA, EMC, FCC, REACH, RoHS, TÜV, FDA
Sustainabilityidentical
Doesn't contain	Lead	Lead
Operational conditionsidentical
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Operating relative humidity (H-H)	0 - 95%	0 - 95%
Storage relative humidity (H-H)	0 - 95%	0 - 95%
Packaging dataidentical
Package type	Box	Box
Logistics dataidentical
Country of origin	China	China

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
